Description
| Measuring Range | 0-100% |
| Accuracy 1 | +/-2% of Full Scale |
| Signal Output 2 | 7-14 mV |
| Linearity | +/-2% of Full Scale |
| Response T90 | 9 sec |
| Temperature Coefficient | Compensated |
| Operating Temp | 0 to 45°C |
| Recommended Storage 3 | 0 to 25°C |
| Temperature Coefficient | Compensated |
| Shelf Life 4 | 6 months |
| Humidity Non-condensing | 0-99% RH |
| Expected Life 2 | 42 months |
| Warranty 5 | 14 months |
| Electrical Connector | 4 Pin Molex |
* Conditions – Specification validated during design and in pursuit of improvement are subject to change without notice
Note:
- 1) At constant temperature and pressure.
- 2) In air (20.9% oxygen) at 25°C and 1 atm. Expected life varies inversely with changes in O2 concentration, temperature, pressure.
- 3) Sensor may be stored up to 55°C on an intermittent basis, for example, during transportation.
- 4) In original Package at 25°C and 1 atm.
- 5) Under normal operating conditions, the sensor is warranted to be free of defects in material and workmanship for the specified period provided the sensor is properly installed and operated. The sole remedy for sensor determined to be defective by Analytical Industries Inc. is limited to replacing the sensor. Analytical Industries Inc. will not be liable for buyer???s negligence, misapplication, abuse or accident.
